Key Specifications Verified in Our Lab
| Parameter | PFTH13 Test Result | Industry Average |
|---|---|---|
| Thrust Capacity | 2,200N ±3% | 1,800N |
| Waterproof | IP66 (72h salt spray) | IP54 |
| Noise Level | ≤48dB @ 100% load | ≤55dB |
| Power Efficiency | 92% @ 36V DC | 85% |
"When Guangzhou Hospital upgraded 300 patient beds, our 24V DC actuators reduced noise to 46dB – critical for ICU rest. Pro tip: Add limit switches to prevent over-extension (error rate ↓78%)."
"In Dubai’s 50°C desert, PFTH13 actuators with temper-resistant seals achieved 99.3% uptime vs. 91% in standard models. Key modification: Graphite-coated lead screws prevent sand jamming."
Step-by-Step: Calculate Your Stroke Length
The PFTH13 actuator operates at an ultra-low noise level of ≤48dB under 100% load (and has reached 46dB in hospital bed applications), making it exceptionally quiet and ideal for critical rest environments like ICUs.
Equipped with temper-resistant seals and graphite-coated lead screws, the PFTH13 prevents sand jamming and maintains a 99.3% uptime even in extreme temperatures up to 50°C, compared to just 91% for standard models.
The actuator is certified with an IP66 rating and has undergone rigorous 72-hour salt spray testing, providing superior protection compared to the industry average of IP54.
You can use the formula: Required Stroke = (H1 - H2) + 10% Safety Margin. For example, if your max height (H1) is 110cm and min height (H2) is 65cm, the calculation yields 49.5cm, meaning a 500mm actuator is the recommended choice.
Ignoring the duty cycle can lead to premature mechanism failure. For instance, using a standard 20% duty cycle actuator in continuous 24/7 operations can result in costly breakdowns. Always request 100% duty cycle certification for continuous use cases.
The PFTH13 delivers a high power efficiency of 92% at 36V DC, which is significantly higher than the typical industry average of 85%.
